Specifications:
- Nominal diameter 170 mm (6.69 in)
- Nominal impedance 8 ohms
- Minimum impedance 6.0 ohms
- Nominal power handling 200 W
- Continuous power handling 400 W
- Sensitivity (1W/1m) 93.0 dB
- Frequency range 70 - 5000 Hz
- Voice coil diameter 44 mm
- Winding material Copper
- Former material Glass Fibre
- Winding depth 12 mm
- Magnetic gap depth 6 mm
- Flux density 1.4 T
Design:
- Surround shape Roll
- Cone shape Radial
- Magnet material Ferrite Ring
- Spider Single
- Pole design Straight Pole
- Woofer cone treatment WP Waterproof Front Side
- Recommended enclosure 9.0 dm3
- Recommended tuning 70 Hz
Parameters:
- Fs 71 Hz
- Re 5.3 ohms
- Qes 0.34
- Qms 12.5
- Qts 0.33
- Vas 7.0 dm3
- Sd 132.0 cm2
- Reference efficiency 0.7 %
- Xmax 4.5 mm
- Xvar 6.0 mm
- Mms 18 g
- Bl 11.0 Txm
- Le 0.7 mH
- EBP 208 Hz
Mounting And Shipping Info:
- Overall diameter 187 mm
- Bolt circle diameter 172 mm
- Baffle cutout diameter 145.0 mm
- Depth 90 mm
- Flange and gasket thickness 11 mm
- Air volume occupied by driver 0.9 dm3
- Net weight 2.5 kg
- Shipping weight 2.7kg
- Shipping box 405x225x210 mm
- Service Kit RCK06PS448
|
